Hrad Disk Capacity |
1TB |
|
Recording Time |
Hard Disk Drive |
DR Mode [Approx.]-HD (15 Mbps) |
140 h*2 |
|
DR Mode [Approx.]-SD (8 Mbps) |
264 h*2 |
|
HG/ HX/ HE/ HL/ HM Mode [Approx.] |
157 h/ 235 h/ 353 h/ 472 h/ 684 h |
|
XP/ SP/ LP/ EP Mode [Approx.] |
215 h/ 431 h/ 862 h/ 1724 h |
|
USB |
Slot |
yes (2) |
|
Front |
yes |
|
Rear |
yes |
|
USB Standard |
USB 2.0 High Speed |
|
Playback |
Mass Strage - MPEG2/ MP4/ Xvid/ MKV/JPEG/MPO |
yes(Without Xvid) |
|
Mass Strage - AAC/ ALAC/ DSD/ FLAC/ MP3/ WMA/ WAV |
yes |
|
External HDD - Broadcast Stream |
yes |
|
Copy(Transfer) |
Mass Strage - to HDD |
MP4, AVCHD, AVCHD 3D, MKV, JPEG, MPO, AAC, ALAC, DSD, FLAC, MP3, WMA, WAV |
|
High Quality Picture |
4K Direct Chroma Up-scaling |
yes*3 |
|
4K Video Playback (4K 24/25/30p) |
yes*4 |
|
4K JPEG Playback |
yes |
|
2D-3D Conversion/ 3D Effect Controller |
yes/yes |
|
High Quality Sound |
96kHz Surround Re-Master |
yes*5（Without CD/DVD-V/BD) |
|
Easy Operation |
Keyword Recording |
yes |
|
TV Series Recording |
yes |
|
Pause Live TV & Rewind Live TV |
yes |
|
Quick Operation - Direct Navigator |
yes*6 |
|
Quick Operation - EPG |
yes*6 |
|
TV Guide Viewing Operation (Portrait / Landscape) |
yes |
|
VIERA Link |
yes |
|
Smart Networking |
Smartphone Apps |
TV Anywhere - Multiroom TV Streaming |
yes*9 |
|
TV Anywhere - Remote Recording |
yes*7*8 |
|
TV Anywhere - Remote Viewing |
yes*8*9*10 |
|
Panasonic Media Center App |
yes*11 |
|
Extra Storage with External HDD |
yes |
|
Miracast |
yes*13 |
|
Internet |
Web Browser |
yes*8*12 |
|
Internet Apps |
yes*8 |
|
DLNA |
as a client |
MPEG, MP4, AVCHD, MKV, JPEG, AAC, ALAC, DSD, Dolby Digital, FLAC, LPCM, MP3, Vorbis, WMA, WAV |
|
as a client (PC) |
Windows 7/8 support |
|
as a server |
MPEG/ AVCHD/ JPEG |
|
Wireless LAN System |
yes (Built-in) |
|
Terminal |
HDMI Output |
yes |
|
Digital Audio Output |
Coaxial |
|
LAN (Ethernet) Terminal |
yes |
|
Tuner |
Tuner System |
DVB-T x 2 |
|
Channel Coverage |
VHF: 6-12, UHF: 27-69 |
|
Others |
HDMI Cable Included |
yes |
|
Power Supply |
AC 220-240V, 50Hz |
|
Power Consumption |
Normal Use |
24W |
|
Standby (Quick Start Off, RF OUT(Aerial Signal) Off) |
0.2W |
|
Dimensions, Weight |
Main Unit |
Dimensions (W x H x D) |
430 x 41.5 x 179 mm*15 |
|
Weight |
1.8 kg |
|
NOTE |
*1 Discs recorded and finalized on recording devices. |
|
NOTE |
*2 The bit rates are approximate. Recording time of DR mode may vary depending on bit rate of broadcasting. |
|
NOTE |
*3 For 4K Up-scaling playback a TV with same resolution is required. |
|
NOTE |
*4 MP4(4K 24p/25p,30p)bit rate up to 100Mbps/resolution up to 3840x2160 25p/30p, 4096x2160 24p. |
|
NOTE |
*5 Sampling frequency is set to 88.2kHz at CD playback. |
|
NOTE |
*6 "Quick Start" needs to be set to "ON" and "Power Save for Network Standby" needs to be set to "OFF" to activate "Quick Start". |
|
NOTE |
*7 Requires browser in PC(except the Remote Viewing), smartphone or tablet. |
|
NOTE |
*8 Requires broadband internet service. |
|
NOTE |
*9 Remote Viewing and Multiroom TV Streaming are not possible for some pay-per-view programs. |
|
NOTE |
*10 Access is possible for only one device (for the BWT955, two devices) at a time. |
|
NOTE |
*11 Download on the App Store. Download on Google Play™. |
|
NOTE |
*12 Recorder's web browser doesn't support flash & some characters' set (e.g. Chinese etc.). |
|
NOTE |
Some features of websites may not be available on the web browser. |
|
NOTE |
*13 Compatible with AndroidTM devices, Ver.4.2 and above and Miracast certified. |
|
NOTE |
For information on whether the smartphone, etc. supports Miracast, contact the manufacturer of the device. |
|
NOTE |
*14 The Lumix camera must support DLNA (DMR) function. |
|
NOTE |
*15 Excluding the projecting parts. |
|
WARNING |
The recording and playback of content on this or any other device may require permission from the owner of the copyright or other such rights in that content. Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. It is your responsibility to ensure that your use of this or any other device complies with applicable copyright legislation in your country. Please refer to that legislation for more information on the relevant laws and regulations involved or contact the owner of the rights in the content you wish to record or playback. Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use. Specifications are subject to change without notice. All numbers given here are approximate. |
|
TRADEMARK NOTICE |
Blu-ray Disc™, Blu-ray™, and the logos are trademarks of Blu-ray Disc Association. "AVCHD" and the "AVCHD" logo are trademarks of Panasonic Corporation and Sony Corporation. DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the Digital Living Network Alliance. MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. DVB and the DVB logos are trademarks of the DVB Project. Google Play is a trademark of Google Inc. "Miracast" is a trademark of Wi-Fi Alliance® The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries. Dolby Digital is a trademarks of Dolby Laboratories. |
