Power supply |
100-240 V AC, 50/60 Hz |
|
Dimensions (H x W x D) |
Approx. 16.5 mm x 126 mm x 59 mm (excluding protruding sections) |
|
Dimensions (H x W x D) |
- When using the cradle: Approx. 47 mm x 131 mm x 78 mm (excluding protruding sections) |
|
Weight |
Approx. 160 g (including the cradle) |
|
Display |
2.2 type color TFT LCD monitor |
|
Wireless transmission method |
1.9 GHz TDMA-WB |
|
Transmission frequency |
1881.792 MHz - 1897.344 MHz |
|
Transmitting range |
Approx. 70 m (line-of-sight distance) |
|
Talking method |
N/A |
|
Operating temperature |
0 °C to 40 °C |
Wireless Camera
|
Power supply |
Alkaline LR battery x 4 |
|
Battery life |
Battery save mode on: Approx. 6 months (*)(**) |
|
Battery life |
Battery save mode off (Default): Approx. 4 months (*)(**) |
|
Battery life |
(*) When used 5 times a day (displaying images for about 20 seconds each time) at a temperature of 20 °C |
|
Battery life |
(**) Under the condition of using with Panasonic alkaline batteries |
|
Dimensions (H x W x D) |
Wireless unit: Approx. 190 mm x 78 mm x 58 mm (excluding protruding sections) |
|
Dimensions (H x W x D) |
Camera unit: Approx. 37 mm x 87.5 mm x 40 mm (excluding protruding sections) |
|
Weight |
Approx. 390 g (excluding batteries) |
|
Installation method |
Attached to a door |
|
Wireless transmission method |
1.9 GHz TDMA-WB |
|
Transmission frequency |
1881.792 MHz - 1897.344 MHz |
|
Minimum illuminance |
3 lx |
|
Water resistant proprieties |
IPx3 equivalent (camera unit) |
|
Water resistant proprieties |
(IPx3 specifies protection against directly sprayed water from a vertical direction to 60 degrees from both sides) |
|
Viewing angle |
Horizontal: Approx. 120° Vertical: Approx. 90° |
|
Transmitting range |
Approx. 70 m (line-of-sight distance) |
|
Operating temperature |
Wireless unit (indoor use) 0 °C to 40 °C Camera unit (outdoor use) -10 °C to 50 °C |
