DISPLAY |
Screen Size (Diagonal) |
47 inch (1,192 mm) |
|
Panel Type |
IPS/E-LED |
|
Aspect Ratio |
16:9 |
|
Effective Display Area (W x H) |
1,039 mm x 584 mm |
|
Number of Pixels (H x V) |
1,920 x 1,080 pixels |
|
Brightness |
1,000 cd/m2 (Typ) |
|
Contrast Ratio |
1,200:1 |
|
Viewing angle (Horizontal/Vertical) |
178° |
|
Panel Life Time |
Approx. 50,000 hours |
|
CONNECTION TERMINAL |
HDMI IN |
HDMI TYPE A Connector x 1 |
|
DVI-D IN / AUDIO IN (L/R) |
DVI-D 24-pin x 1 / M3 Jack x 1 (Shared with PC IN) |
|
PC IN / AUDIO IN (L/R) |
Mini D-sub 15-pin x 1 (Female) / M3 jack x 1 (Shared with DVI-D IN) |
|
DIGITAL LINK |
RJ45 x 1 (Shared with DIGITAL LINK) |
|
CONTROL |
SERIAL IN |
D-sub 9-pin x 1 / x1, RS-232C Compatible |
|
LAN |
RJ45 x 1 (Shared with DIGITAL LINK) |
|
AUDIO |
Line Out (VAO) |
RCA Pin (L/R) x 1 set |
|
ELECTRICAL |
Power Requirements |
220 – 240 V AC, 50Hz/60Hz |
|
Power Consumption |
370 W |
|
Power-off Condition |
approx. 0.3 W |
|
Stand-by Condition |
approx. 0.5 W |
|
Outdoor Mode ON |
approx. 41 W |
|
Network Stand-By Mode |
approx. 16 W |
|
MECHANICAL |
Dimensions (W x H x D) |
1,162 x 706 x 216 mm |
|
Weight |
Approx. 49.5 Kg |
|
Cabinet Material / Colour |
Aluminium / Black (Front cabinet) & Silver (Back cover) |
|
Protection Glass |
Yes |
|
Mounting Method |
VESA Compliant 400 x 400 mm |
|
ENVIRONMENTAL |
Direct Sunlight capability (Measures Against Blackout) |
Yes (Built-in air cooling system) |
|
Dust and Water Resistant Level |
IP44 |
|
Operating Environment |
Temperature |
0°C to 40°C, -20°C to 40°C (Outdoor mode) |
|
Humidity |
20% to 80% (Non condensation) |
