General Power supply 100-240 V AC, 50/60 Hz
Power consumption 322 W (0.48 W when standby mode set to Eco*1, 12.5 W when standby mode set to Network.)
LCD panel Panel size 15 mm (0.59 inches) diagonal (16:10 aspect ratio)
Display method Transparent LCD panel (x 3, R/G/B)
Pixels 1,024,000 (1,280 x 800) x 3, total of 3,072,000 pixels
Lens 1.6x manual zoom (throw ratio: 1.2–1.9:1), manual focus, F 1.65–2.33, f 15.47–24.53 mm
Lamp 245 W x 1, lamp replacement cycle (lamp power: Normal/Eco1, Eco2): 3,000 hours/5,000 hours*2
Screen size (diagonal) 0.76–7.62 m (30–300 inch)
Brightness 3,000 lm (lamp power: Auto/Normal)
Center-to-corner uniformity*3 85 %
Contrast 2,000:1 (full on/full off, lamp power: Auto)
Resolution 1,280 x 800 pixels*4
Scanning frequency HDMI fH: 25–80 kHz, fV: 50–85 Hz, dot clock: 162 MHz or lower
RGB (analog) fH: 15–100 kHz, fV: 50–100 Hz, dot clock: 140 MHz or lower
(Signals exceeding the dot clock rate of 140 MHz are downsampled.)
YPBPR (YCBCR) fH: 15.75 kHz, fV: 60 Hz [480i(525i)]
fH: 31.50 kHz, fV: 60 Hz [480p(525p)]
fH: 45.00 kHz, fV: 60 Hz [720(750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1080(1125)/60i]
fH: 15.63 kHz, fV: 50 Hz [576i(625i)]
fH: 31.25 kHz, fV: 50 Hz [576p(625p)]
fH: 37.50 kHz, fV: 50 Hz [720(750)/50p]
fH: 28.13 kHz, fV: 50 Hz [1080(1125)/50i]
Video/S-Video fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical axis shift 49:1
Keystone correction range Vertical: ±30° (±20° when Real-Time Keystone)
Installation Ceiling/floor, front/rear
Terminals HDMI IN HDMI 19-pin x 1 (compatible with HDCP)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p,
VGA (640 x 480)-WUXGA (1,920 x 1,200), *6
audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
COMPUTER IN 1 D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR x 1)
COMPUTER IN 2 / MONITOR OUT D-sub HD 15-pin (female) x 1 (RGB x 1), (input/output selectable using on-screen menu)
(When Monitor Out is selected, the COMPUTER IN 1 signal is output.)
VIDEO IN RCA pin x 1 (Composite VIDEO)
S-VIDEO IN Mini DIN 4-pin x 1 (S-VIDEO)
AUDIO IN RCA pin x 2 (L-R x 1) for VIDEO/S-VIDEO input
COMPUTER AUDIO IN 1 M3 x 1 (L-R x 1)
COMPUTER AUDIO IN 2 (MIC IN) M3 x 1 (L-R x 1) for audio input or for microphone connection (variable)
AUDIO OUT M3 x 1 (L-R x 1) for output (variable)
SERIAL IN D-sub 9-pin (male) x 1 for external control (RS-232C compliant)
LAN RJ-45 x 1 (for network connection, 10Base-T/100Base-TX, compliant with PJLink™ (class 1))
USB A -
USB B -
Built-in speaker 3.7 cm round shape x 1, output power: 10.0 W (monaural)
Noise level 35 dB (lamp power: Normal), 29 dB (lamp power: Eco1, Eco2)
Cabinet materials Molded plastic
Dimensions (W x H x D) 350 x 97 x 277 mm (13.8" x 3.8" x 10.9")
(with legs at shortest position, not including protruding parts)
Weight Approx. 3.5 kg (7.7 lbs)
Operating environment Operating temperature: 5°C–35°C (41°F–95°F),
operating humidity: 20%–80% (no condensation)
Wireless Standard -
Infrastructure mode -
Ad-hoc mode*7 -
NOTE *1: When the Standby mode is set to Eco, network functions such as standby on via LAN are not available. Also, only certain commands can be received for external control using the serial terminal.
*2: The values given for the recommended lamp replacement cycles are maximum.
*3: Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*4: Input signals that exceed this resolution will be converted to 1,280 x 800 pixels.
*5: Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.
*6: Compliant with VESA CVT-RB.
*7: Not supported by IEEE802.11n.
