General Power supply 100 - 240 V AC, 3.9 - 1.4 A, 50/60 Hz
Power consumption 330 W (0.3 W at 100 - 120 V AC, 0.4 W at 220 - 240 V AC when standby mode set to eco*1, 9 W when standby mode set to normal, 20 W when standby mode set to normal and audio monitor out.)
LCD panel Panel size 20.3 mm (0.8 inches) diagonal (4:3 aspect ratio)
Display method Transparent LCD panel (× 3, R/G/B)
Pixels 786,432 (1,024 × 768) × 3, total of 2,359,296 pixels
Pixel configuration Stripe
Lens Manual 2× zoom (throw ratio: 1.48 - 2.96:1), manual focus F 1.7 - 2.6, f 24.0 - 47.2 mm
Lamp 250 W UHM lamp (The lamp replacement cycle is 6,000 hours.*2)
Screen size (diagonal) 0.84 - 7.62 m (33 - 300 inches), 4:3 aspect ratio
Brightness*3 4,000 lm (lamp mode: normal)
Center-to-corner uniformity*3 80%
Contrast*3 600:1 (full on/full off)
Resolution 1,024 × 768 pixels (Input signals that exceed this resolution will be converted to 1,024 × 768 pixels.)
Scanning frequency HDMI/DVI-I (digital) fH: 27.0 kHz - 68.7 kHz; fV: 24.0 Hz - 85.0 Hz; dot clock: 25.2 MHz - 148.5 MHz
DVI-I (analog)/RGB fH: 15 .6 kHz - 91.1 kHz; fV: 24.0 Hz - 85.1 Hz; dot clock: 162 MHz or lower
YPBPR (YCBCR) fH: 15.63 kHz; fV: 50 Hz [576i (625i)]
fH: 31.25 kHz; fV: 50 Hz [576p (625p)]
fH: 37.50 kHz; fV: 50 Hz [720 (750)/50p]
fH: 28.13 kHz; fV: 50 Hz [1080 (1125)/50i]
fH: 33.75 kHz; fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]
Video/S-Video fH: 15.75 kHz; fV: 60 Hz (NTSC/NTSC4.43/PAL-M/PAL60), fH: 15.63 kHz; fV: 50 Hz (PAL/PAL-N/SECAM)
Optical axis shift Vertical ±50% from center of screen (manual)
Horizontal ±27% from center of screen (manual)
Keystone correction range Vertical: ±30°
Installation Ceiling/desk, front/rear
Built-in speaker Output power: 5.0 W (monaural)
Terminals HDMI IN HDMI 19-pin × 1 (Deep Color, compatible with HDCP)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/60p, 1080/50p,
VGA (640 × 480) - WSXGA+ (1,680 × 1,050), compatible with non-interlaced signals only;
dot clock: 25.2 - 146.25 MHz;
Audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
DVI-I IN DVI-I 29-pin × 1
Digital: (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/60p, 1080/50p,
VGA (640 × 480) - WSXGA+ (1,680 × 1,050), compatible with non-interlaced signals only;
dot clock: 25.2 - 146.25 MHz;
Analog: (RGB/YPBPR (YCBCR))
COMPUTER (RGB) IN D-sub HD 15-pin (female) × 1 (RGB/YPBPR × 1)
VIDEO IN RCA pin × 1 (composite video)
S-VIDEO IN Mini DIN 4-pin × 1 (S-Video)
AUDIO IN 1 M3 × 1 (L, R × 1), 0.5 Vrms
AUDIO IN 2 M3 × 1 (L, R × 1), 0.5 Vrms
AUDIO IN 3 RCA pin × 2 (L, R × 1), 0.5 Vrms
AUDIO OUT M3 × 1 (L, R × 1) (monitor out: 0 - 2.0 Vrms, variable)
SERIAL IN D-sub 9-pin (female) × 1 for external control (RS-232C compliant)
LAN RJ-45 × 1 (for network connection, 10Base-T/100Base-TX, compliant with PJLink™)
WIRELESS MODULE Connector for optional wireless module ET-WM200 × 1
Cabinet materials Molded plastic (PC+ABS)
Dimensions (W × H × D) 430 × 125.5*4 × 323 mm (16 - 15/16˝ × 4 - 15/16˝ *4 × 12-23/32˝ ) (Protruding parts not included)
Weight Approximately 6.0 kg (13.2 lbs.)
Operating environment Operating temperature: 0°C - 40°C (32°F - 104°F)*5; operating humidity: 20% - 80% (no condensation)
NOTE *1 When the standby mode is set to eco, network functions such as power on over the LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*2 This value is calculated by continuously turning the lamp on for 2 hours and off for 0.25 hours. The lamp replacement cycle will decrease if the lamp is turned on/off more frequently, or if it is left on for longer intervals.
*3 Measurement, measuring conditions and method of notation all comply with ISO 21118 international standards.
*4 With legs at shortest position.
*5 The operating temperature range is 0°C to 35°C (32°F to 95°F) when used in High- Altitude mode (1,400 m to 2,700 m (4,593 ft to 8,858 ft)).
