General DLP™ chip Panel size 17.8 mm (0.70 inches) diagonal (4:3 aspect ratio)
Display method DLP™ chip x 1, DLP™ projection system
Pixels 786,432 (1,024 x 768) pixels
Lens Manual zoom (2x zoom), manual focus F 2.0-3.4, f 21.5-43.0 mm
Lamp 300 W (max. 310 W) UHM lamp
Screen size 1.02-7.62 m (40- 300 inches), 4:3 aspect ratio
Brightness*1 4,500 lumens (lamp mode: NORMAL)
Center-to-corner uniformity*1 90%
Contrast*1 2,000:1 (full on/full off)
Resolution 1,024 x 768 pixels (Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.)
Scanning frequency HDMI/DVI-D fH: 27 kHz-100 kHz, fV: 24 Hz-120 Hz, dot clock: 25 MHz-162 MHz
RGB fH: 15 kHz-100 kHz, fV: 24 Hz-120 Hz, dot clock: 162 MHz or lower
YPBPR (YCBCR) 480i (525i): fH 15.75 kHz; fV 60 Hz
576i (625i): fH 15.63 kHz; fV 50 Hz
480p (525p): fH 31.50 kHz; fV 60 Hz
576p (625p): fH 31.25 kHz; fV 50 Hz
720 (750)/60p: fH 45.00 kHz; fV 60 Hz
720 (750)/50p: fH 37.50 kHz; fV 50 Hz
1035/60i: fH 33.75 kHz; fV 60 Hz
1080 (1125)/60i: fH 33.75 kHz; fV 60 Hz
1080 (1125)/50i: fH 28.13 kHz; fV 50 Hz
1080/25p: fH 28.13 kHz; fV 25 Hz
1080/24p: fH 27.00 kHz; fV 24 Hz
1080/24sF: fH 27.00 kHz; fV 48 Hz
1080/30p: fH 33.75 kHz; fV 30 Hz
1080/60p: fH 67.50 kHz; fV 60 Hz
1080/50p: fH 56.25 kHz; fV 50 Hz
Video/S-Video fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical axis shift Vertical +60% from center of screen (manual)
Horizontal ±10% from center of screen (manual)
Keystone correction range Vertical ±40ﾟ
Installation Ceiling/floor, front/rear
Terminals HDMI IN HDMI 19-pin x 1 (Deep Color, compatible with HDCP)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,
VGA (640 x 480) -WUXGA (1,920 x 1,200)*2; compatible with non-interlaced signals only; dot clock: 25-162 MHz
Audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
DVI-D IN DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,
VGA (640 x 480)-WUXGA (1,920 x 1,200)*2; compatible with non-interlaced signals only; dot clock: 25-162 MHz
RGB 1 IN BNC x 5 (RGB/ YPBPR x 1)
RGB 2 IN D-sub HD 15-pin (female) x 1 (RGB/ YPBPR x 1)
VIDEO IN BNC x 1 (composite video)
S-VIDEO IN Mini DIN 4-pin x 1 (S-Video)
AUDIO IN 1 RCA x 2 (L, R x 1), 0.5 Vrms
AUDIO IN 2 M3 x 1 (L, R x 1), 0.5 Vrms
AUDIO IN 3 M3 x 1 (L, R x 1), 0.5 Vrms
AUDIO OUT M3 x 1 (L, R x 1) (monitor out: 0-2.0 Vrms, variable)
SERIAL IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
REMOTE IN D-sub 9-pin (female) x 1 for external control (contact control)
LAN RJ-45 x 1 (for network connection, 10Base-T/100Base-TX, compliant with PJLink™)
WIRELESS MODULE Connector for optional wireless module ET-WM200 x 1
Power cord length 3.0 m (9 ft 10 in)
Power supply 100-240 V AC, 5.0-1.9 A, 50/60 Hz
Power consumption 415 W (500 VA) (0.3 W at 100-120 V AC, 0.4 W at 220-240 V AC with standby mode set to ECO*3, 15 W with standby mode set to NORMAL)
Dimensions (W x H x D) 332 x 168*4 x 484.5 mm (13-1/16˝ x 6-5/8˝ *4 x 19-1/16˝ ) (including the lens)
Weight Approximately 8.5 kg (18.7 lbs.)
Operating temperature 0°C-45°C (32°F-113°F)
Operating humidity 20%-80% (no condensation)
NOTE *1: Measurement, measuring conditions and method of notation all comply with ISO 21118 international standards.
*2: Compliant with VESA CVT-RB.
*3: When the standby mode is set to ECO, network functions such as power on over the LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*4: With legs at shortest position.
