Panel Type                                   0.65" DLP x 1
Lamp                                           N.A. (Laser diodes light source)
Brightness                                    6,500 lumens
Lens                                             F1.7-1.9, f25.6-35.7mm
Contrast (Full on / Full off)         10000:1
Resolution (Native / maximum)  WXGA (1280x800)
Video Compatibility                    PAL, PAL-M, PAL-N, PAL60, SECAM, NTSC, NTSC4.43
Screen Size                                  50" - 600"
Lens Shift                                    Vertical +60%, -16%, horizontal +30%, -10%
Keystone Correction Range        Vertical ±40°
Weight                                         23.2kg
Dimensions (W x H x D)             498 x 200 x 581 mm
Power Consumption                    720W
Terminals                                     HDMI (19-pin x 1)
DVI-D (24-pin x 1)
RGB1 (BNC x 5)
RGB2 (D-sub HD 15-pin (female) x 1)
Serial (D-sub 9-pin x 1)
LAN/ Digital Link (RJ-45 x 1)
Remote1,2 in；Remote1 out
Optional Accessories                   ET-PKD120H (High ceiling mount bracket)
ET-PKD120S (Low ceiling mount bracket)
ET-PKD130H (6 axis adjustment high ceiling mount bracket)
ET-PKD130B (Attachment for ceiling mount bracket)
Optional Lens                              Optional Lens         -
                  Zoom lens                  ET-DLE085 (zoom lens, 0.8-1.0:1)
ET-DLE150 (zoom lens, 1.4-2.0:1)
ET-DLE250 (zoom lens, 2.4-3.8:1)
ET-DLE350 (zoom lens, 3.8-5.7:1)
ET-DLE450 (zoom lens, 5.6-9.0:1)
                  Fixed focus lens         ET-DLE030 (fixed focus lens, 0.4:1)
ET-DLE055 (fixed focus lens, 0.8:1)
