Display
Screen Size
65-inch (1638 mm)
Panel Type
VA Panel/E-LED
Aspect Ratio
16:09
Effective Display Area
1428 x 803 mm
(W x H)
(56.2″ x 31.6″)
Number of Pixels (H x V)
1920 x 1080 pixels
Brightness (Typ)
350 cd/m
2
Contrast Ratio
5000:1
Response Time
6.5 ms (G to G)
Viewing Angle (Horizontal/Vertical)
176°/176°
(CR≥20)
Connection Terminal
VIDEO IN
4-pole mini jack (M3) x 1
HDMI In
HDMI TYPE-A connector x 2 * VIERA LINK is not supported.
DVI-D In/Audio In (L/R)
DVI-D 24-pin x 1/Stereo Mini Jack (M3) x 1 (Shared with PC In)
PC In/Audio In (L/R)
Mini D-sub 15-pin x 1/Stereo Mini Jack (M3) x 1 (Shared with DVI-D In)
USB
USB connector (TYPE A) x 1, DC 5V/1A * USB 3.0 is not supported.
Control
Serial
D-sub 9-pin x 1, RS-232C Compatible
LAN
RJ45 x 1 10 BASE-T/100BASE-TX, Compatible with PJLink™
IR In/Out
Mini Jack (M3) x 1/ x 1
Audio
Audio Out
Stereo Mini Jack (M3) x 1
Built-in Speaker
20 W [10 W + 10 W] (10% THD)
Electrical
Power Requirements
110-127/220-240 V AC, 50/60 Hz
Power Consumption
160 W
On Mode Average Power Consumption*1
115 W
Power off Condition
Approx. 0.3 W
Stand-by Condition
Approx. 0.5 W
Mechanical
Dimensions (W x H x D)
1451 x 829 x 62 mm (57.2″ x 32.7″ x 2.5″)
Bezel Width
7.5 mm (0.3″) (L/R/T), 10.5 mm (0.42″) (B)
Weight
Approx. 36.2 kg
(79.9 lbs.)
Pitch of Wall-hanging
VESA Compliant 400 x 400 mm
(15.8″ x 15.8″)
Installation Requirement
Orientation
Landscape / Portrait
Tilting Angle
0-20 degrees forward with landscape setting
*2
Operating Environment
Temperature: 0°C to 40 °C (32 °F to 104 °F)
*3 / Humidity: 20 % to 80 % (Non Condensation)
*4
NOTE
*1 Based on IEC 62087 Ed.2 measurement method.
*2 Please contact your sales representative with regard to the tilt angle before installation.
*3 Environmental temperature to use this unit at high altitudes (1400 m (4593 ft) and higher and below 2800 m (9186 ft) above sea level): 0 °C to 35 °C (32 °F to 95°F)
*4 Depending on the temperature or humidity conditions, uneven brightness may be observed. This is not a malfunction.
• This unevenness will disappear while applying current continuously. If not, consult the distributor.
