Model |
TH-55LFV5 |
TH-47LFV5 |
|
Display |
Screen Size |
55-inch (1,387.8 mm) |
47-inch (1,192 mm) |
|
Panel Type |
IPS/Direct LED |
|
Effective Display Area (W x H) |
1,209 x 680 mm (47.7" x 26.8") |
1,039 x 584 mm (40.9" x 23.0") |
|
Resolution (H x V) |
1,920 x 1,080 pixels |
1,920 x 1,080 pixels |
|
Brightness (Typ) |
500 cd/m2 |
500 cd/m2 |
|
Contrast Ratio |
1,400:1 |
1,400:1 |
|
Dynamic Contrast Ratio |
500,000:1 |
500,000:1 |
|
Viewing Angle (Horizontal/Vertical) |
178°/178° |
178°/178° |
|
Operating Life |
Approx.60,000 hours
(Backlight half-life) |
Approx.60,000 hours
(Backlight half-life) |
|
Panel Surface Treatment |
Anti-glare Treatment (Haze 10 %) |
Anti-glare Treatment (Haze 10 %) |
|
Connection Terminal |
VIDEO In/AUDIO In (L/R) |
BNC x 1, Pin Jack x 1 set (Shared with Component In) |
|
HDMI In |
HDMI Type A x 1 |
|
COMPONENT In/AUDIO In (L/R) |
BNC x 1 set, Pin Jack x 1 set (Shared with Video In) |
|
DVI-D In |
DVI-D 24-pin x 1, Stereo Mini Jack (M3) x 1 (Shared with PC In) |
|
PC In/AUDIO In (L/R) |
Mini D-Sub 15-pin x 1, Stereo Mini Jack (M3) x 1 (Shared with DVI-D In) |
|
DVI-Out |
DVI-I 29-pin x 1, Pin Jack x 1 set |
|
Control |
Serial In/Out |
D-Sub 9-pin x 1/x 1, RS-232C Compatible |
|
LAN |
RJ45 x 1 (Web browser control only) |
|
IR Transmitter In/Out |
IR x 1/x 1 |
|
Audio |
Speaker Out |
8 Ω 20W (10 W + 10 W) |
|
Electrical |
Power Requirements |
110-127 V AC/220-240 V AC, 50/60 Hz |
110-127 V AC/220-240 V AC, 50/60 Hz |
|
Power Consumption |
220 W |
160 W |
|
Power off Condition |
Approx. 0.3 W |
Approx. 0.3 W |
|
Stand-by Condition |
Approx. 0.5 W |
Approx.0.5 W |
|
Mechanical |
Dimensions |
1,216 x 687 x 122 mm (47.9" x 27.1" x 4.8" ) |
1,045 x 590 x 109 mm (41.2" x 23.3 " x 4.3") |
|
Weight (Approx.) |
36.0 kg (79.3 lbs) |
25.0 kg (55.1 lbs.) |
|
Bezel Width |
3.4 mm (0.14") [Left/Top], 1.9 mm (0.08") [Right/Bottom] |
3.2 mm (0.12") [Left/Top], 1.7 mm (0.07") [Right/Bottom] |
|
Bezel to Bezel |
5.3 mm (0.21") [Multi Screen] |
4.9 mm (0.19") [Multi-Screen] |
|
Operation Environment |
Temperature |
0°C to 40°C (32°F to 104°F) |
|
Humidity (Non condensation) |
10 % to 90 % |
