Weight |
- |
|
Accessories |
- |
|
Power Requirement |
- |
|
Interface |
- |
|
Image Compression |
- |
|
Image Output |
- |
|
Other Functions |
- |
|
Storage Environment |
- |
|
Scanning Face |
- |
|
Scanning Method |
- |
|
Scanning Resolution |
- |
|
Automatic Detection |
- |
|
Image Control |
- |
|
FEED TRAY CAPACITY |
- |
|
Stacker capacity |
- |
|
Supported Operating System |
- |
|
EXTERNAL DIMENSIONS (W X D X H) |
- |
|
Accessories (CD-ROM) |
- |
|
Consumables Roller exchange kit |
- |
|
Options Flatbed Scanner |
- |
|
Light source |
- |
|
Internal Video Processing |
- |
|
Accessories |
Quick Installation Guide, Power Cord, USB Cable, Shading paper |
|
Accessories (CD-ROM) |
CD-ROM: Device driver, ISIS driver software, TWAIN driver software, WIA driver software, Image Capture Plus, Operating Manual, Control sheet, MCD utility, User utility, Scan Button Setting Tool, Network Scanner Select Tool, Network Setting Tool |
|
Automatic Detection |
Intelligent double feed detection |
|
Consumables Roller cleaning paper |
KV-SS03 |
|
Consumables Roller exchange kit |
KV-SS068 |
|
ADF Document(Size) |
Manual feeding: 1.9in. x2.75 in. to 12.1in. x 220in.Automatic feeding: 1.9 in. x2.75 in. to 12.1 in. x 17 in. |
|
ADF Document(Thickness) |
Paper: 0.04mm - 0.2mm (1.6mils - 7.9mils), Note: 1mil = 0.001in. |
|
ADF Document(Weight) |
5.2lbs. - 41.8lbs. Manual 5.2lbs. - 68lbs. |
|
Double feed detection |
Ultrasonic |
|
EXTERNAL DIMENSIONS (W X D X H) |
18.5in. x 17.5in. x 13.5in. |
|
FEED TRAY CAPACITY |
330 sheets: 20lb Bond |
|
Image Compression |
MH, MMR, JPEG |
|
Image Control |
Auto Preview, Auto Rescan, Automatic Brightness Adjustment, Multi Color Drop Out, Dynamic Threshold, Image Emphasis Gamma, Automatic Separation, Noise Reduction, Faith Character Emphasis, Vertical Line Reduction |
|
Image Output |
Binary 1-bit, Grayscale 8-bit, Color 24-bit, MultiStream (Color & Binary or Gray & Binary) |
|
Interface |
USB 3.2 Gen1 (backward compatible), LAN (10Base-T / 100Base-TX / 1000Base-T) |
|
Internal Video Processing |
1,024 levels (30bit) |
|
Light source |
RGB LED |
|
Options Flatbed Scanner |
KV-SS081 |
|
Options Imprinter Unit |
KV-SS014 |
|
Options Image Capture Plus Add-in |
KV-SS093 (10 license) |
|
Options Image Capture Plus (OCR module for network scan) |
KV-SS094 (10-user license) (KV-S5078Y) |
|
Options Image Capture Plus Zonal OCR Add-in |
KV-SS096 (10 license) |
|
Other Functions |
Length Control, Patchcode Detection (Type 2, 3, T), Control Sheet detection, Long Paper, Double Feed Skip |
|
Power Consumption (Power off) |
0.3W or less (100-127V / 220-240V) |
|
Power Consumption (Sleep) |
1.7W or less (USB connection), 1.7W or less (LAN connection) |
|
Power Consumption Maximum (Scanning) |
90W or less |
|
Power Consumption Minimum (Ready) |
25W or less |
|
Power Requirement |
100V: 100-127V AC 50/60Hz, 1.5A / 200V: 220-240V AC 50/60Hz, 0.8A |
|
Scanning Face |
Duplex |
|
Scanning Method |
3-line color CIS |
|
Scanning Resolution |
50dpi-600dpi (1dpi step) and 1,200dpi (interpolated), Optical: 300/600dpi (Automatic switch) |
|
Stacker capacity |
330 sheets: 21 lbs. (Bond) |
|
Supported Operating System |
Windows 7 (32 bit/64 bit),
Windows 8 (32 bit/64 bit),
Windows 8.1 (32 bit/64 bit),
Windows 10 (32 bit/64 bit),
Windows Server 2008 SP2 (32 bit/64 bit),
Windows Server 2008 R2 SP1 (64 bit),Windows Server 2012 (32 / 64-bit), Windows Server 2016 (32 / 64-bit), Windows Server 2019 (32 / 64-bit) |
|
Weight |
39.2 lbs |
|
Consumables Ink Cartridge |
KV-SS021 |
|
Scanning Speed |
Simplex: Up to 120 ppm, Duplex: Up to 240ipm (Binary/Color, A4/letter, Landscape, 200/300dpi) |
|
Options Consumables Roller exchange kit |
KV-SS068 - 700.000 pages |
