Specification |
Description |
|
Scanning Face |
Duplex |
|
Scanning Method |
Color CIS |
|
Scan Background Color |
Black, White (Selectable) |
|
Resolution |
100 - 600 dpi (1 dpi step), Optical: 600 dpi |
|
Scanning Speed (Binary/Color, A4 Size, 200/300dpi) |
Simplex: Up to 60 ppm*1 (Portrait), Duplex: Up to 120 ipm*1 (Portrait) |
|
Automatic Detection |
Double-feed detection@(1 position), Stapled document detection |
|
Compression |
JPEG (Color, grayscale) |
|
TONAL GRADATION |
Binary, Grayscale (8 bit), Color, MultiStream: Binary & Grayscale, Binary & Color |
|
Binary Mode Halftone |
Dither, Error Diffusion |
|
Image Control |
Dynamic Threshold, Automatic Crop, Automatic Binary/ Colour Distinction, Blank Page Removal, Double Exposure, Multi Colour Dropout, Smooth Background, Hole Removal, Border Removal, Noise Reduction, Detect File Separation Sheet and much more |
|
Other Functions |
Length control, Barcode detection (ISIS), Patch code detection, Automatic separation, Control sheet, Long paper mode |
|
Effective Scanning Width |
227 mm (8.9 in.) |
|
Documents (Paper) |
Size: Min. 48 mm x 70 mm (1.9 in. x 2.8 in.) / Max. : 297 mm x 432 mm (11.7 in. x 17 in.), Thickness: 0.04 mm - 0.2 mm (1.6 mils - 7.9 mils*2) / Straight path max 0.6 mm (23.6 mils*2), Weight*3: 20 g/m2 - 157 g/m2 (5 lbs. - 42 lbs.) |
|
Documents (Card) |
- |
|
FEED TRAY CAPACITY |
Up to 300 sheets (64 g/m2, 17 lbs.) |
|
Supported Operating System |
Windows 2000, Windows XP, Windows Vista |
|
Computer Interface |
USB 2.0 |
|
EXTERNAL DIMENSIONS (W X D X H) |
474 mm x 585 mm x 329 mm (18.7 in. x 23.0 in. x 13.0 in.) |
|
Weight |
25 kg (55 lbs.) |
|
Power Requirement |
AC 100 V - 240 V, 50 / 60 Hz |
|
Power Consumption (AC 100-120V) |
Scanning: 105 W or less, Ready: 27 W or less, Sleep: 2 W or less, Standby: 0.5 W or less |
|
Power Consumption (AC 220-240V) |
Scanning: 100 W or less, Ready: 27 W or less, Sleep: 2 W or less, Standby: 0.5 W or less |
|
Operating environment |
10 - 35 C (50 - 95 F), 20 - 80 % RH |
|
Storage Environment |
0 - 40 C (32 - 104 F), 10 - 80 % RH |
|
Accessories |
CD-ROM (Device driver software, Operation manual, Installation manual, Control data sheet, Image Capture Plus software*4, ISIS/TWAIN driver, software, User utility software, Multi colour dropout utility), Power cord, USB cable, Blower |
|
ROLLER EXCHANGE KIT |
KV-SS033 |
|
ROLLER CLEANING PAPER |
KV-SS03 |
|
Imprinter Unit |
KV-SS014 (Pre and/or Post) |
|
Ink cartridge |
KV-SS021 |
|
Optional Flatbed Scanner |
KV-SS081, KV-S080*5 |
|
Footnote |
*1 The scanning speed is as determined by Panasonic methods of speed measurement. The scanning speed differs depending on the host computer, the operating system, the application, the measuring method, the quantity of data in the image and the paper type. *2 1 mil = 0.001 in. *3 "Weight in pounds" of paper represents the weight of 500 sheets (432 x 559 mm / 17 x 22 in.) *4 The supported file types are PDF, PDF/A, Searchable PDF, Searchable PDF/A, JPEG, JPEG2000, TIFF and Bitmap.Searchable PDF and Searchable PDF/A documents can be created for English, French, German, Italian, Spanish, Brazilian Portuguese, Japanese, Korean, Simplified Chinese, and Traditional Chinese. Searchable PDF and Searchable PDF/A documents for Japanese, Korean, Simplified Chinese, and Traditional Chinese can be created when using Operating Systems of the respective languages. *5 KV-SS081 and KV-SS080 are not available for certain countries. Please contact our dealer and confirm the availability. |
|
Scanning Speed |
Simplex: Up to 60 ppm*1 (Portrait), Duplex: Up to 120 ipm*1 (Portrait)
(Binary/Color, A4 size, 200/300 dpi) |
