PLAYABLE DISCS |
DVD |
DVD-Video |
yes |
|
DVD-R*1/ DVD-R DL*1/ DVD-RW*1 |
DVD-Video |
yes |
|
MP3/ Xvid/ JPEG/ MOV |
yes |
|
+R*1/ +R DL*1/ +RW*1 |
Video |
yes |
|
CD, CD-R/ -RW |
CD-DA |
yes |
|
MP3/ Xvid/ JPEG |
yes |
|
AUDIO SYSTEM |
Output Channel |
5.1ch |
|
Power Output - Home Theater Mode (RMS) |
Total Power |
300W |
|
Front |
50W/ch (1kHz, 4ohms, 30% THD) |
|
Center |
50W (1kHz, 4ohms, 30% THD) |
|
Surround |
50W/ch (1kHz, 4ohms, 30% THD) |
|
Subwoofer |
50W (70Hz, 8ohms, 30% THD) |
|
Dolby Digital |
yes |
|
Dolby Pro Logic II |
yes |
|
USB |
Slot |
yes |
|
Front |
For Playback |
|
USB Standard |
USB 2.0 High Speed |
|
Playback |
MP3/ Xvid/ JPEG/ MOV/ FLV |
yes |
|
HIGH QUALITY PICTURE |
1080p Up-Conversion with HDMI |
yes |
|
HIGH QUALITY SOUND |
Powerful Bass-reflex Subwoofer |
yes |
|
EQ/ Subwoofer Level |
yes |
|
EASY OPERATION |
Selectable Speaker Layout (Front Speaker Layout) |
yes |
|
Wall Mountable Speaker |
yes |
|
ARC (Audio Return Channel)*2 |
yes |
|
SMART NETWORKING |
External HDD Playback*3 |
yes |
|
SPEAKER SYSTEM |
Front |
Configuration |
1-way 1 speaker, Bass-reflex |
|
Speaker Unit [Approx.] |
Full Range: 6.5cm Cone Type |
|
Center |
Configuration |
1-way 1 speaker, Bass-reflex |
|
Speaker Unit [Approx.] |
Full Range: 6.5cm Cone Type |
|
Surround |
Configuration |
1-way 1 speaker, Bass-reflex |
|
Speaker Unit [Approx.] |
Full Range: 6.5cm Cone Type |
|
Subwoofer |
Configuration |
1-way 1 speaker, Bass-reflex |
|
Speaker Unit [Approx.] |
Woofer: 16cm Cone Type |
|
TERMINAL |
HDMI Output |
yes |
|
Video Output |
yes |
|
Digital Audio Input |
- |
|
Analog Audio Input (AUX) |
Pin Jack |
yes |
|
Mic Jack (6.3mm) |
- |
|
OTHERS |
Video System |
PAL/ NTSC |
|
Power Supply |
AC 220-240V, 50/60Hz |
|
Power Consumption |
Normal Use [Approx.] |
41W |
|
Standby [Approx.] |
0.5W |
|
Band/ Station Presets |
FM/ 30 |
|
HDMI Cable Included |
yes |
|
DIMENSIONS, WEIGHT |
Main Unit |
Dimensions (W x H x D) [Approx.] |
430 x 55 x 322 mm |
|
Weight [Approx.] |
2.3 kg |
|
Front Speaker |
Dimensions (W x H x D) [Approx.] |
81 x 126 x 74 mm |
|
Weight [Approx.] |
0.43 kg |
|
Speaker Cable Length |
3 m |
|
Center Speaker |
Dimensions (W x H x D) [Approx.] |
81 x 126 x 74 mm |
|
Weight [Approx.] |
0.43 kg |
|
Speaker Cable Length |
2 m |
|
Surround Speaker |
Dimensions (W x H x D) [Approx.] |
81 x 126 x 74 mm |
|
Weight [Approx.] |
0.43 kg |
|
Speaker Cable Length |
6.5 m |
|
Subwoofer |
Dimensions (W x H x D) [Approx.] |
156 x 290 x 263 mm |
|
Weight [Approx.] |
3.1 kg |
|
Speaker Cable Length |
3 m |
|
NOTE |
*1 Discs recorded and finalized on recording devices. |
|
NOTE |
*2 ARC compatible TV is required. |
|
NOTE |
*3 The external HDD with capacities of 2TB or less in processing NTFS/ FAT32 data is supported. Playback is not possible with some external hard disk drives. |
|
NOTE |
*4 Full assembly with stand base. |
|
NOTE |
Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use. |
|
NOTE |
Specifications are subject to change without notice. |
|
