1/2.86"-type Full-HD 3MOS

1000 TV lines Typ (center area)

Auto, 0 dB to 36 dB

59.94p/59.94i: 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 29.97p: 1/30, 1/60, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 23.98p: 1/24, 1/60, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 50p/50i: 1/60, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 25p: 1/25, 1/60, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000

AWB A, AWB B, ATW, 3200 K, 5600 K, VAR (2000 K to 15000 K)

1080/59.94p, 1080/29.97p, 1080/23.98p, 1080/59.94i, 1080/29.97PsF, 1080/23.98PsF, 720/59.94p, 480/59.94p(i), 1080/50p, 1080/25p, 1080/50i, 80/25PsF, 720/50p, 576/50p(i)

Motorized 20 zoom

F1.6 to F3.4

f=4.5 mm to 90 mm; 35 mm equivalent: 32.13 mm to 642.5 mm

Entire zooming range: 800 mm ,Wide end: 400 mm

2.5 V ±0.5 V

-40 dBV ± 3 dBV (0 dB=1 V/Pa, 1 kHz) approximately

-10 dBV ±3 dBV approximately

Stand-alone (Desktop) or suspended (Hanging)

0.08°/s to 60°/s

±175°

–30° to 210°

Input: RJ-45, IP control, RS-422 3.5 mm stereo mini jack, mic/line BNC, 12 VDC G/L Black Burst Sync

Output: HDMI (HDCP and Viera Link not supported) BNC, HD/SD SDI BNC, video

HDMI HD / SD SDI: SMPTE424 / SMPTE292 / SMPTE259 standards 75 ohms NTSC / PAL 1.0 V p-p / 75 ohms

12 VDC (AC adaptor supplied) 42 - 57 VDC (PoE+ power supply)

1.8 A (AC adaptor supplied) 0.6 A (PoE+ power supply)

Operating Temperature: 0 to 40°C Storage Temperature: -20 to 50°C

Operating Humidity: 20 % to 90 %

180 x 228 x 234 mm, excluding protrusions, cable cover, and direct ceiling mount bracket
