External Dimensions |
1010 x 870 x 2010 (mm) / 39.8 x 34.3 x 79.1 (inch) |
|
Internal Dimensions |
870 x 600 x 1400 (mm) / 34.3 x 23.6 x 55.1 (inch) |
|
Effective Capacity |
728 liters (25.7 cu.ft.) |
|
Exterior Cabinet |
Painted steel |
|
Internal Cabinet |
Painted steel |
|
Doors |
Painted steel |
|
Shelves |
3 pcs, stainless steel tray |
|
Access Ports |
17 mm diameter, 3 locations (back, bottom left / right corner) |
|
Net Weight |
Approx. 375 kg (827 lbs.) |
|
Compressor |
2 compressors, hermetic 1100 W |
|
Evaporator |
Tube on sheet type |
|
Condenser |
Finless tube type |
|
Refrigerant |
HFC |
|
Temperature Control Range |
– 50 °C to – 86 °C (in 1 °C increments) |
|
Temperature Display |
Digital Display |
|
Alarms |
High / low temperature, Door ajar, Power failure, Remote alarm contact(Allowable contact capacity: DC 30 V, 2 A), Part replacement notification, Fan lock alarm, Refrigeration circuit abnormal alarm |
|
Accessories |
1 scraper, Vacuum release port cleaning gear, 1 set of keys |
