AUDIO SYSTEM |
Output Channel |
2ch |
|
Power Output (RMS/ PMPO) |
Total Power |
550W/ 6000W |
|
Total Power |
Front: 275W (1kHz, 3ohms, 30% THD) |
|
PLAYABLE DISCS |
DVD |
DVD-Video |
yes |
|
MP3 |
- |
|
JPEG |
- |
|
Xvid |
yes |
|
DVD-R*1/ DVD-R DL*1/ DVD-RW*1 |
DVD-Video |
yes |
|
MP3 |
yes(DVD-R/ DVD-RW) |
|
JPEG |
yes(DVD-R/ DVD-RW) |
|
Xvid |
yes |
|
+R*1/ +R DL*1/ +RW*1 |
Video |
yes |
|
CD, CD-R/ -RW |
CD-DA |
yes |
|
Video CD |
yes |
|
SVCD |
yes |
|
MP3 |
yes |
|
JPEG |
yes |
|
Xvid |
yes |
|
USB |
Slot |
yes (2) |
|
USB Standard |
USB 2.0 Full Speed |
|
Playback |
MP3 |
yes |
|
JPEG |
yes |
|
Xvid |
yes |
|
Recording Speed |
Normal Speed only |
|
TUNER |
Band/ Station Presets |
FM/ 30, AM/15 |
|
Auto Tuning |
yes |
|
Frequency Range |
FM 87.5-108.0MHz 50Hz step), |
|
Frequency Range |
AM 522 - 1629kHz (9kHz step) |
|
Frequency Range |
520 - 1630kHz (10kHz step) |
|
|
|
|
|
|
|
|
HIGH QUALITY PICTURE |
1080p Up-Conversion with HDMI |
yes |
|
HIGH QUALITY SOUND |
Digital Amplifier |
yes |
|
D.Bass |
yes |
|
Maximized Bass Sound PLUS |
yes |
|
Local Preset Equalizer |
yes |
|
Manual Equalizer |
yes (Bass/ Mid/ Treble) |
|
Surround |
yes |
|
Bluetooth® Re-Master |
yes |
|
EASY OPERATION |
DJ Jukebox |
yes (Crossfade) |
|
Double USB Sharing |
yes(Play & Rec/ Play) |
|
6 Key for Karaoke |
yes |
|
Rotary Music Selection while Playback |
yes |
|
Karaoke Function |
yes (Full Karaoke) |
|
Display |
Fluorescent |
|
Auto Power Off |
yes |
|
Programmable Timer |
PLAY/ REC/ SLEEP |
|
DESIGN |
Illumination |
yes (3 Color) |
|
SPEAKER SYSTEM |
Front |
Configuration |
2-way 2 speakers, Bass-reflex |
|
Speaker Unit |
Woofer : 20 cm Cone Type |
|
Speaker Unit |
Tweeter: 6 cm Cone Type |
|
TERMINAL |
HDMI Output |
yes |
|
Video Output |
yes |
|
Optical Input |
- |
|
Analog Audio Input (AUX) |
Pin Jack |
yes |
|
3.5 mm Jack |
yes |
|
MIC Jack (6.3 mm) |
yes (2) |
|
OTHERS |
Power Supply |
AC 220-240V, 50/60Hz |
|
Power Consumption |
|
SMART NETWORKING |
Bluetooth® Wireless Technology |
yes |
|
MAX JUKE App Compatible*2 |
yes |
Normal Use [Approx.] |
81W |
|
Normal Standby [Approx.] |
0.5W |
|
DIMENSIONS, WEIGHT |
Main Unit |
Dimensions (W x H x D) [Approx.] |
230 x 335 x 249mm |
|
Weight [Approx.] |
3.1 kg |
|
Front Speaker |
Dimensions (W x H x D) [Approx.] |
250 x 429 x 226 mm |
|
Weight [Approx.] |
4.0 kg |
|
External Super Wooder |
Dimensions (W x H x D) [Approx.] |
- |
|
Weight [Approx.] |
- |
|
NOTE |
*1 Discs recorded and finalized on recording devices. |
|
NOTE |
*2 Download on the App Store. Download on Google Play™. |
|
NOTE |
Specifications are subject to change without notice. |
|
