Picture Quality |
Display |
Panel |
4K HDR |
|
GENERAL ITEMS |
OSD LANGUAGES |
ME/AF:ENGLISH/FARSI/ FRENCH/ARABIC/PORTUGUESE |
|
MANUAL LANGUAGES |
ME/AF:ENGLISH/FRENCH/ARABIC/PORTUGUESE |
|
SUPPLY TYPE |
ME/AF: CBU |
|
DESTINATION |
ME/AF |
|
FC COLOUR |
DARK GREY with painting process |
|
TUNNING |
NUMBER OF PROGRAMS |
999 |
|
COLOUR SYSTEM |
PAL, DVB-T/T2 |
|
SOUND SYSTEM |
BG / I / DK |
|
DTV SYSTEM |
DVB-T/T2 |
|
BASIC INFO |
CPU |
Dual Core A53 1.5GHz |
|
GPU |
Quad Core MALI450MP2 |
|
OS |
LINUX V3.10 |
|
MEMORY FLASH |
1.5GB DDR3/4GB EMMC |
|
INTERNET LINK |
BUILD IN WIFI,ETHERNET NETWORK |
|
PICTURE |
RESOLUTION |
3840X2160 |
|
ASPECT RATIO |
16:9/4:3/Just Scan/Auto |
|
DNR (Noise Reduction) |
YES, Off/Low/Middle/High/Auto |
|
Picture Mode |
Cinema/Standard/Vivid/User/Game |
|
AUDIO |
AUDIO OUTPUT POWER (RMS) |
10W x 2 |
|
SPEAKER TYPE |
Box |
|
FEATURES |
HOTEL MODE |
Yes |
|
PANASONIC LOGO |
YES |
|
CEC |
YES |
|
SOUND OUT(ARC） |
YES |
|
DIGITAL DOLBY |
Yes |
|
ANY OTHER (PLEASE SPECIFY) |
Netflix,Youtube, Icflix, wireless display, App store(ZEASN)，Browser |
|
CONNECTIVITY |
RF IN |
YES |
|
DTV IN |
Common with RF |
|
AV1 IN |
YES |
|
|
|
|
|
RESOLUTION |
3840(H) X 2160 (V) |
|
|
|
USB INPUT (3.0 SUPPORT) |
1 |
|
USB INPUT (2.0 SUPPORT) |
1 |
|
HDMI INPUT(2.0 SUPPORT) |
3 |
|
HEADPHONE OUT |
YES |
|
PC AUDIO IN |
NO |
|
PC(VGA IN) |
NO |
|
MHL |
NO |
|
AUDIO OUT |
YES |
|
SPDIF OUT |
YES |
|
RJ-45 |
YES |
|
ANY OTHER (PLEASE SPECIFY) |
NO |
|
MULTIMEDIA SUPPORT |
USB DEVICE SUPPORT |
USB 2.0 & 3.0 |
|
PICTURE FORMAT |
Jpeg/Png/BMP |
|
AUDIO FORMAT |
MP3/MPEG1/AC3/EAC3/PCM/AAC/HE-AAC /DD+ |
|
VIDEO FORMAT |
Video:MPEG1.2.4/WMV/VC1/H.265/VP8
Audio:MPEG1/AC3/EAC3/PCM/AAC/HE-AAC /DD+ |
|
PANEL SPECIFICATIONS |
PANEL MODEL NO. AND TYPE |
LGD(LC490EGY-SKM3)/ IPS |
|
SCREEN SIZE & DIAGONAL |
49” / 123CM |
|
ASPECT RATIO |
16:09 |
|
|
|
|
DISPLAY AREA(H x V) |
1073.78(H) X 604.00(V) |
|
PIXEL PITCH |
0.279(H) X 0.279(V) |
|
DISPLAY COLOURS |
10bit(D), 1.07Billon colors |
|
CONTRAST RATIO |
1000:1 |
|
MAX BRIGHTNESS |
300cd/m2 |
|
VIEWING ANGLE (HORIZONTAL / VERTICAL) |
178°/178° |
|
WEIGHT AND DIMN. |
NET WEIGHT WITH PEDESTAL |
11.7kg |
|
NET WEIGHT W/O PEDESTAL |
11.5kg |
|
NET DIMENSIONS WITH PEDESTAL |
1102.1 x 693.2 x 267.4MM |
|
NET DIMENSIONS W/O PEDESTAL |
1102.1 x 646.7 x 79.8MM |
|
GROSS DIMENSIONS (PACKING BOX) |
1250x152x783 |
|
GROSS WEIGHT (WITH PACKING BOX) |
15.9KG |
|
RATING |
OPERATING VOLTAGE |
100V-240V~ at 50/60Hz |
|
POWER CONSUMPTION |
125 W |
|
STD BY POWER CONSUMPTION |
≤0.5W |
|
ACCESSORIES |
|
|
|
|
|
|
POWER CORD TYPE |
Detachable |
|
POWER CORD |
ME/AF: VED 2PIN+BS 3PIN |
|
POWER PLUG |
2 PIN |
|
ANY OTHER (PLEASE SPECIFY) |
-- |
|
REGULATION |
BIS |
No |
|
CB |
YES |
|
ERP |
YES |
|
EMC |
YES |
|
BEE |
NO |
|
ANY OTHER (PLEASE SPECIFY) |
RTT&E |
