Model number |
UB-7320
(UB-718B) *¹
T/H *² |
|
Power Supply |
AC 100-120V, 50 / 60Hz or AC 220-240V, 50 / 60Hz |
Power Consumption
(Operational / Standby) |
1.40A (AC 100-120V) / 0.18A (AC 100-120V)
0.75A (AC 220-240V) / 0.08A (AC 220-240V) |
Eternal Dimensions
(Height x Width x Depth(mm))
Without Stand |
1,504 x 1,648 x 287 |
|
Weight (without stand) |
41kg |
|
Ambient Operating Conditions |
Temperature : 10-35°C , Humidity : 30-80%RH |
|
Writing Implements |
Dry erase felt-tipped markers (black, red and blue) |
Panel Dimensions
Height x Width (mm) |
900 x 1,400 |
|
Panel Surface |
4 (endless type)*³ |
Copying Area
Height x Width (mm) |
850 x 1,330 |
|
Scanning System |
Contact Image sensors |
|
Printing System |
Thermal type |
|
Copy Paper |
Heat-sensitive roll paper |
|
Copy Paper Size |
A4 or Letter*4 |
|
Copy Density |
203dpi(8dots/mm) |
|
Copy Color |
Black |
|
Contrast Adjustment |
Two levels : Normal / Dark |
|
2-screen Compressed Copying |
No |
|
Time required for Copying |
16 sec. / sheet |
|
Continuous Copies |
1 to 9 |
|
Paper Empty Indication |
Yes |
|
Computer Interfacing System Requirements |
Computer |
IBM® PC/AT or compatible machine with a CD-ROM drive |
|
CPU |
Pentium® || or higher processor |
|
Interface |
USB 1.1 or USB 2.0*5 (B connector) |
|
OS |
Windows Vista(TM)(32 bit)*6, Windows® 98 / Me / 2000 / XP |
|
Memory |
64MB or more (Windows®
128MB or more (Windows®
256MB or more (Windows®
512MB or more (Windows Vista(TM)*6) 98 / Me) 2000) XP) |
|
HD |
At least 240MB free space
(except saving space for image file) |
|
Accessories |
-
Markers (Black, Red, Blue)
-
Erase(one pc.)
-
Software CD-ROM
-
Operating instructions, Installation manual
-
Power code
-
A4 or Letter Size Copy Paper Roll(10 m)
|
|
Separately Available |
|
|
|
Wall-Mounting Kit |
KX-B063 |
|
Copy Paper |
KX-B01 (1 roll/50 m), KX-B02 (1 roll/100 m) |
|
Markers |
KX-B031 (10 black markers), KX-B032 (10 red markers),
KX-B033 (10 blue markers) |
|
Erasers |
KX-B042 (set of 6 erasers) |
|
Marker and Eraser Set |
KX-B035 (contains 1 black, 1 red, and 1 blue markers and 1 eraser) |
