SIP Trunking
• VoIP Extensions (Proprietary and SIP)
• DECT Multi-Cell Wireless
• PC-Based Programming
• DXDP (Digital Extra Device Port)
• Automatic Route Selection (ARS)
• Toll Restriction
• Digital Voice Mail Integration
• Enhanced System Networking
• Uniform Call Distribution (UCD)
• Direct Inward System Access (DISA)
• IP Address is built into the MPR
• ISDN Primary Rate Interface (PRI) with QSIG
• T1 for Trunking and Point-to-Point
• Analog (POTS) CO Line Trunking
• Caller ID (Name & Number)
• VoIP Gateway with QSIG (Enhanced System Networking)
• IP Gateway is built into the DSP Card
1 Physical Shelf with 6 Free Universal Slots
1 Virtual Shelf with 2 Trunk Slots & 2 Trunk Slots & 2 Extension Slots
1 Main Processor Unit
1 SD Card

NOTE: Power supply or accessory cards are not included with the KX-TDE200 and must be added as needed based on a specific configuration.

Maximum System Capacity

Maximum Number of Trunks
From Physical Shelf	112	Note 1
From Virtual Shelf	64	Note 2
Not to Exceed Total for Physical & Virtual Shelves	128	Note 3



Maximum Number of Extensions
From Physical Shelf	160	Note 1
From Virtual Shelf	128	Note 2
Not to Exceed Total for Physical & Virtual Shelves	160	Note 3

Note 1: The KX-TDE100 Physical Shelf has a total of 6 Free Universal Slots. Universal, meaning any slot can accommodate any type of trunk, extension or option card (with limitations). The density of each card varies by type. For instance ... Co Trunk Cards are available in 8 or 16 trunks per card. ISDN-PRI and T! cards are available in 23 channels (trunks) per card and 24 channels (trunks) per card respectively. Extensions are available in 8/16 per card or 16/32 using the DXPD feature. Each time you populate a slot with a physical card, you are effecting the ratio of Trunks -to- Extensions. Example: A configuration using all physical slots for 112 trunks means that there is no room for physical extensions or special option cards such as Door Controllers, UCD/DISA, etc. Likewise, a configuration using all physical slots for 160 extensions means that there is no room for Trunks or special option cards such as Door Controllers, UCD/DISA, etc.
Note 2: The KX-TDE100 Virtual Shelf has a total of 4 Slots - 2 are Trunk related and 2 are Extension related. Each trunk slot can accommodate 32 trunks for a total of 64 Virtual Trunks. Slots accept either SIP CO Lines or H.323 CO Lines provided that no more than 32 of these are H.323.
Note 3: Totals are somewhat dynamic. Even though the maximum number of trunks is 128 and the maximum number of extensions is 160, you cannot realize both at the same time since you would run out of slots. Your Panasonic Certified Dealer will help you balance these maximums so as to optimize the system for future growth.
